SA213 T12 Tube

Energy Steel Industrial Co., Ltd.
Steel Fabrication,Nickel Alloy Steel Tube,Stainless Steel Tube

Category

SA213 T12 Tube

SA213 T12 BOILER TUBE, A213 T12 MATERIAL SUPPLIER

STOCKIST OF SA213 T12 TUBE, ASME SA213 GRADE T12 SEAMLESS TUBE SUPPLIERS, SA 213 T12 TUBING AND ALLOY STEEL T12 PIPE MANUFACTURER IN China

If you have been searching for A213 T12 Tube Materials suppliers in China, then you are at the right place. All sizes in SA213 GR T12 Tube, SA213 T12 Tube are available upon request. Energy Steel Industrial is a leading exporter & supplier of SA213 T12 Tubing, SA213 T12 welded Tubes and T12 Tube Material for industrial applications requiring tight tolerances, enhanced mechanical properties and superior surface finish requirements.Energy Steel Industrial is one of the leading ASTM A213 Gr T12 Tubing suppliers in China. We continues to deliver unmatched value to this market by providing easy access to the largest SA213 T12 Seamless Alloy Tube & ASTM A213 Grade T12 heat exchanger tubing inventories in China. Standard IBR certified SA213 T12 Boiler Tube include ASME SA213 Grade T12 Seamless Tube, SA213 T12 Material and SA 213 T12 High Pressure Tube.


Our ASTM A213 T12 Tubes inventories are located in Mumbai, Chennai and Ahmedabad to supply global industrial markets. Available delivery conditions for ASTM A213 Grade T12 IBR Tube include as-drawn, stress relieved and normalized annealed. We also offers one of the world’s widest ranges of ASTM A213 T12 Tube for feed water heaters (FWH). Strategically located manufacturing plants produce SA213 T12 Boiler Tube, SA213 T12 seamless or A213 Gr T12 welded carbon steel tubes, including low alloy steels, such as SA213 T22, for use in high pressure (HP) heaters. Energy Steel Industrial has a wide range of mill cut lengths SA213 Gr T12 Pipe in the industry, produced and delivered direct from our mill locations.

  • SA213 GR T12 TUBE
  • SA213 T12 BOILER TUBE
  • T12 TUBE MATERIALS
SA213 T12 BOILER TUBE PRICE IN China
Size" MSL Make ISMT make JSL Make
1/2" 2,352.94 2,345.59 2,360.29
3/4" 2,132.35 2,125.00 2,139.71
1" 1,985.29 1,977.94 1,992.65
1.25" 1,941.18 1,933.82 1,948.53
1.5" 1,838.24 1,830.88 1,845.59
ASTM A213 T12 BOILER TUBE SPECIFICATIONS
SA213 T12 Tube Standard ASTM A213 T12, SA213 T12 (with IBR Test Certificate)
SA213 T12 Tube Specifications ASTM A213 & ASTM A209 (T1 , Ta, T1b)
BS/3059/90/PartII/620 & 622
DIN/17175/13CrMo44
DIN/17175/10CrMo910
DIN/17175/15Mo3
SA213 T12 Tube Size 6.35 mm OD to 101.6 mm OD
Sch. & Swg. 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg., 3.6 mm Thk
SA213 T12 Tube Thickness 3-12mm
SA213 T12 Tube Origin European, Japanese, Korean, US, Russian, Indian
SA213 T12 Tube Tolerance Cold drawn pipe: +/-0.1mm
Cold rolled pipe: +/-0.05mm
Craft Cold rolled and Cold drawn
SA213 T12 Tube Type Seamless / ERW / Welded / Fabricated
SA213 T12 Tube available in Form of Round, Square, Rectangular, Hydraulic Etc.
SA213 T12 Tube Length Standard
Double &
In Cut length also.
SA213 T12 Tube End Plain End, Beveled End, Treaded
Specialized in ASME SA213 T12 Boiler Tube, SA213 T12 Heater Tube, SA213 T12 Heat Exchanger Tube
SA213 gr T12 Additional Testing NACE MR 0175, NACE TM0177, NACE TM0284, HIC TEST, SSC TEST, H2 SERVICE, IBR, etc.
SA213 grade T12 Tube Application Seamless Ferritic Alloy Steel Tube for High-Temperature Service
ASTM A213 T12 EQUIVALENT

SA213 GR T12 EQUIVALENT

SA213 T12 Equivalent Standards: EN 10216-2, ASTM A335, GOST 550-75, DIN 17175, BS 3059 Part II, NF A 49-213
SA213 Gr T12 Equivalent Material: T12, K21590

13CrMo44, 10CrMo910, 10CrMo9-10, 1.7380, 11CrMo9-10, 1.7383, P22, 622-490, TU 10 CD 9-10


Trade Name  Grade UNS # Heater Tubes
1 1/4 Chrome  T11 K11597  A213 / SA213
2 1/4 Chrome  T22 K21590  A213 / SA213
5 Chrome  T5 K41545  A213 / SA213
9 Chrome  T9 K90941 A213 / SA213
T91 T91 K90901 A213 / SA213
T92 T92 K92460 A213 / SA213

MATERIAL SPECIFICATION
ASTM ASME
CHROME- MOLY ALLOY STEEL TUBE SEAMLESS ASTM A213 T5 5% Chrome; ½% Moly SA213 T5 5% Chrome; ½% Moly
CHROME- MOLY ALLOY STEEL TUBE SEAMLESS ASTM A213 T9 9% Chrome; 1% Moly SA213 T9 9% Chrome; 1% Moly
CHROME- MOLY ALLOY STEEL TUBE SEAMLESS ASTM A213 T11 1-1/4% Chrome; ½% Moly SA213 T11 1-1/4% Chrome; ½% Moly
CHROME- MOLY ALLOY STEEL TUBE SEAMLESS ASTM A213 T22 2-1/4% Chrome; 1% Moly SA213 T22 2-1/4% Chrome; 1% Moly
CHROME- MOLY ALLOY STEEL TUBE SEAMLESS ASTM A213 T91 9% Chrome; 1% Moly + trace elements SA213 T91 9% Chrome; 1% Moly + trace elements
T12 TUBE COMPOSITION

ASTM A213 /SA213 T12 Boiler Tube Chemical Composition

Grade C≤ Mn P≤ S≤ Si≤ Mo
T12 0.15 max 0.30~0.60 0.025 0.025 0.50~1.0 0.44~0.65


SA213 T12 MECHANICAL PROPERTIES

CHROME MOLY TUBES SA213 T12 PROPERTIES & SA213 T12 THERMAL CONDUCTIVITY

Grade Tensile Strength, MPa Yield Strength, MPa Elongation, % Hardness, HB
T12 415 min 220 min 30 min 163 max

ALLOY STEEL T12 SEAMLESS TUBE OUTSIDE DIAMETER AND TOLERANCE

Outside Diameter OD Tolerance WT Tolerance Ovality Tolerance Cut Length Tolerance
OD≤ 12, 7 mm ± 0, 13 mm ± 15 % – + 3, 18 mm, – 0 mm
12, 7 mm < OD ≤ 38, 1 mm ± 0, 13 mm ± 10 % max, 1, 65 mm + 3, 18 mm, – 0 mm
38, 1 mm < OD ≤ 88, 9 mm ± 0, 25 mm ± 10 % max, 2, 41 mm + 4, 76 mm, – 0 mm
ASTM A213/ ASME SA213 T12 ALLOY STEEL TUBE WALL THICKNESS & TOLERANCE
Hot rolled ASTM A213/ ASME SA213 T12 Alloy Steel Tube
Outside Diameter, mm Tolerance, %

OD≤101.6, WT≤2.4

+40/-0
OD≤101.6, 2.4＜WT≤3.8 +35/-0
OD≤101.6, 3.8＜WT≤4.6 +33/-0
OD≤101.6, WT>4.6 +28/-0
OD>101.6, 2.4＜WT≤3.8 +35/-0
OD>101.6, 3.8＜WT≤4.6 +33/-0
OD>101.6, WT>4.6 +28/-0
Cold Drawn ASTM A213/ ASME SA213 T12 Alloy Steel Tube
Outside Diameter, mm Tolerance, %
OD≤38.1 +20/-0
OD>38.1 +22/-0

Length: 5800mm; 6000mm; 6096mm; 11800mm; 12000mm; and so on.
Max length: 16000mm


ASTM A213 T12 Tube Types Out diameter Wall thickness Length
SA213 T12 Seamless Tube (Custom Sizes) 1/2" NB - 60" NB As per requirement Custom
ASTM A213 T12 Welded Tube (in Stock + Custom Sizes) 1/2" NB - 24" NB As per requirement Custom
ASME SA213 T12 Tubing (Custom Sizes) 1/2" NB - 24" NB As per requirement Custom
ASTM A213 High Pressure T12 Boiler Tube 16" NB - 100" NB As per requirement Custom
THE TABLES BELOW SHOW OUR READY STOCK OF ASTM A213 T12 TUBES
ASTM A213 T12 Beveled End Tubing IBR Certified T12 Steel Grade Tube
ASTM A213 T12 Tube ASME SA213 T12 Boiler Tube
High Pressure T12 Alloy Steel Tube A213 T12 Welded Tube
ASME SA213 Gr T12 Tubing T12 Alloy Steel IBR Approved Boiler Tubing
ASTM A213 Grade T12 Tubes A213 T12 Steel Seamless Tubing
ASTM A213 Gr T12 IBR Approved Tube ASTM SA213 T12 IBR Certified Tubing
SA213 T12 ERW Tubes Alloy Steel T12 Boiler Tubes
A213 Gr T12 Beveled End Tubes SA213 Grade T12 High Pressure Tubes
SA213 T12 Steel IBR Approved Tubing Steel T12 Boiler Tubing
SA213 T12 Steel Welded Tubing A213 T12 Steel Hydraulic Tube
ASME SA213 Grade T12 ERW Tube IBR ASME SA213 Gr T12 Tube
ASME SA213 T12 Welded Tubes T12 Alloy Steel IBR Tubing
SA 213 T12 IBR Approved Boiler Tubes ASTM A213 Grade T12 Round Tubes
A213 Gr T12 Seamless Tube SA213 Gr T12 IBR Certified Boiler Tubes
Plain End Beveled SA213 T12 Steel Tubing A213 T12 Steel Square Tubing
ASTM A213 Gr T12 Seamless Tubes ASME SA213 Gr T12 ERW Tubing
T12 Steel Grade High Strength Seamless Tube ASTM A213 T12 Plain End Beveled Tubes
SA213 Gr T12 Single Random Length Tubing SA213 Grade T12 IBR Approved Boiler Tube
T12 IBR Certified Tubes SA213 T12 Round Tube
ASME SA213 Grade T12 Square Tube ASTM A213 Grade T12 IBR Tubes
SA213 Grade T12 Hot rolled Tubing T12 Steel Grade Oval Tube
A213 T12 Small Bore Tube High Strength Steel T12 Tube
A213 Grade T12 Double Random Tubing Double Random ASTM A213 Gr T12 Tubes
A213 Grade T12 Cold Drawn Tube 20mm SA213 Grade T12 Tube
T12 Steel Grade High Strength Round Tube Large Diameter A213 Grade T12 Tube
Alloy Steel T12 Cold Drawn Tubes 40mm ASME SA213 T12 Tube
Alloy Steel T12 IBR Certified Boiler Tube Plain End Beveled T12 Tube
ASTM A213 Gr T12 Round Tubing ASTM A213 T12 Single Random Length Tubes
Steel T12 IBR Certified Boiler Tubing A213 Grade T12 IBR Approved Tubes
ASME SA213 T12 High Pressure Tubing Double Random A213 Gr T12 Tube
A213 Gr T12 Square Tubes 10mm SA213 T12 Tube
Steel T12 High Strength Rectangular Tube ASTM SA213 T12 Beveled End Tube
A213 T12 Steel Rectangular Tubes ASME SA213 Grade T12 Rectangular Tubing
Single Random Length SA213 Gr T12 Tube 50mm A213 T12 Tube
ASTM A213 Grade T12 Rectangular Tube ASTM SA213 T12 Hot rolled Tubes
SA213 T12 Hydraulic Tubing Cold Drawn Tubing
ASME SA213 Gr T12 Hot rolled Tube Alloy Steel T12 High Strength Seamless Tube
T12 Hydraulic Tubes ASME SA213 Grade T12 Perforated Tube
A213 T12 30mm Tube ASTM SA213 T12 Scaffold Tube
SA213 T12 BOILER TUBE WEIGHT CHART
Size NPS Pipe O.D. Wall Thickness Pipe I.D. Weight per Foot Standard to XXHY Schedule
Pipe # 		Section Modulus Gallon Capacity Per Linear Foot
1/2 0.84 0.109 0.622 0.85 STD 40 .0407 .0158
    0.147 0.546 1.09 XHY 80 .0478 .0122
    0.188 0.464 1.31   160 .0528 .0088
    0.294 0.252 1.72 XXHY   .0577 .0026
3/4 1.05 0.113 0.824 1.13 STD 40 .0705 .0277
    0.154 0.742 1.48 XHY 80 .0853 .0225
    0.219 0.612 1.95   160 .1006 .0153
    0.308 0.434 2.44 XXHY   .1103 .0077
1 1.315 0.133 1.049 1.68 STD 40 .1328 .0449
    0.179 0.957 2.17 XHY 80 .1606 .0374
    0.250 0.815 2.85   160 .1904 .0271
    0.358 0.599 3.66 XXHY   .2136 .0146
1 1/4 1.66 0.140 1.380 2.27 STD 40 .2346 .0777
    0.191 1.278 3.00 XHY 80 .2913 .0666
    0.250 1.160 3.77   160 .3421 .0549
    0.382 0.896 5.22     .4110 .0328
1 1/2 1.90 0.145 1.610 2.72 STD 40 .3262 .1058
    0.200 1.500 3.63 XHY 80 .4118 .0918
    0.281 1.338 4.86   160 .5079 .0730
    0.400 1.100 6.41     .5977 .0494
2 2.375 0.109 2.157 2.64   10 .4205 .1898
    0.154 2.067 3.66 STD 40 .5606 .1743
    0.218 1.939 5.03 XHY 80 .7309 .1534
    0.250 1.875 5.68     .8045 .1434
    0.281 1.813 6.29     .8666 .1344
    0.344 1.687 7.47   160 .9806 .1161
    0.436 1.503 9.04 XXHY   1.1043 .0922
2 1/2 2.875 0.120 2.635 3.53   10 .6870 .2833
    0.203 2.469 5.80 STD. 40 1.0640 .2487
    0.216 2.443 6.14     1.1169 .2435
    0.250 2.375 7.02     1.2468 .2301
    0.276 2.323 7.67 XHY 80 1.3386 .2202
    0.375 2.125 10.02   160 1.6371 .1842
    0.552 1.771 13.71 XXXHY   1.9971 .1280
3 3.50 0.120 3.260 4.34     1.0411 .4336
    0.156 3.188 5.58     1.3122 .4147
    0.172 3.156 6.12     1.4265 .4064
    0.188 3.124 6.66     1.5342 .3984
    0.216 3.068 7.58 STD. 40 1.7241 .3840
    0.250 3.000 8.69     1.9372 .3672
    0.281 2.938 9.67     2.1207 .3521
    0.300 2.900 10.26 XHY 80 2.2253 .3431
    0.438 2.624 14.34   160 2.8774 .2811
    0.600 2.300 18.6 XXHY   3.4243 .2158
3 1/2 4.0 0.120 3.760 4.98   10 1.3776 .5768
    0.226 3.548 9.12 STD. 140 2.3939 .5136
    0.250 3.500 10.02     2.6001 .4998
    0.281 3.438 11.17     2.8562 .4821
    0.318 3.364 12.52 XHY 80 3.1400 .4617
    0.636 2..728 22.87 XXHY   4.8795 .3085
4 4.5 0.120 4.260 5.62   10 1.7612 .7404
    0.156 4.188 7.24     2.2354 .7156
    0.188 4.124 8.67     2.6296 .6942
    0.203 4.094 9.32     2.8173 .6838
    0.219 4.062 10.02     3.0184 .6725
    0.237 4.026 10.80 STD. 40 3.2145 .6613
    0.250 4.000 11.36     3.3611 .6528
    0.281 3.938 12.67   60 3.7021 .6326
    0.312 3.876 13.97     4.0273 .6126
    0.337 3.826 15.00 XHY 80 4.2713 .5972
    0.438 3.624 19.02   120 5.1790 .5361
    0.531 3.438 22.53   160 5.8997 .4822
    0.674 3.152 27.57 XXHY   6.7927 .4054
5 5.563 0.188 5.187 10.80     4.1161 1.0979
    0.219 5.125 12.51     4.7279 1.0716
    0.258 5.047 14.63 STD. 40 5.4500 1.0391
    0.281 5.001 15.87     5.8644 1.0204
    0.312 4.939 17.51     6.4074 .99647
    0.344 4.875 19.19     6.9358 .9696
    0.375 4.813 20.80 XHY 80 7.4300 .9449
    0.500 4.563 27.06   120 9.2534 .8495
    0.625 4.313 32.99   160 10.7976 .7590
    0.750 4.063 38.59 XXHY   12.0954 .6734
6 6.625 0.109 6.407 7.59   5 3.5769 1.6748
    0.134 6.357 9.30   10 4.3475 1.6488
    0.156 6.313 10.79     5.0107 1.6260
    0.188 6.249 12.94     5.9351 1.5937
    0.203 6.219 13.94     6.3804 1.5780
    0.219 6.187 15.00     6.8261 1.5620
    0.250 6.125 17.04     7.6905 1.5306
    0.280 6.065 18.99 STD. 40 8.4958 1.5008
    0.312 6.001 21.06     9.3416 1.4688
    0.344 5.937 23.10     10.111 1.4391
    0.375 5.875 25.05     10.893 1.4082
    0.432 5.761 28.60 XHY 80 12.224 1.3541
    0.500 5.625 32.74     13.711 1.2909
    0.562 5.501 36.43   120 14.9806 1.2346
    0.625 5.375 40.09     16.1821 1.1787
    0.719 5.187 45.39   160 17.8243 1.0977
    0.864 4.897 53.21 XXHY   20.025 .9784
    1.000 4.625 60.13     21.7719 .8727
    1.125 4.375 66.14     23.1237 .7809

ALLOY STEEL T12 TUBE MATERIAL EXPORTER IN INDIA, MANUFACTURER OF ASTM A213 GRADE T12 BOILER TUBE
ASME SA213 T12 TUBING SUPPLIERS IN INDIA, SA213 T12 MATERIAL DISTRIBUTOR AND SA213 T12 BOILER TUBE STOCKIST IN MUMBAI, INDIA
